| Event Action |
System Events |
Tamper Detection, Alarm In, Virtual Alarm In, Video Loss/Recovery, Disarm, Recurrence, Login, System Start |
|
Action Handlers |
HTTP, TCP, FTP, E-mail, S3, VMS, Onvif, Audio Back Channel (Camera speaker) |
|
Combining Rules with Other Events |
Yes |
|
Pre/Post Snapshot |
Yes |
|
Annotated Video Stream |
Yes |
| Video |
Max. Video Input Resolution |
4K @ 30 fps (2M @ 120 fps) |
|
Video Input Method |
RTSP, RTSP over HTTP/S, Onvif |
|
Supported Input Video Format |
H.265 / H.264 |
|
Video Output Stream Method |
RTSP over TCP/UDP, RTSP over Websocket, RTSP over HTTP/S |
| Audio |
Audio Input |
1 x Audio Line-In (3.5mm audio phone jack) |
|
Audio Output |
1 x Audio Line-Out (3.5mm audio phone jack) |
| Interface |
USB |
1 x USB2.0 |
|
LAN |
2 x 10/100/1000 BASE-T Ethernet (ETH1/ETH2) |
| Alarm I/O |
Alarm Input |
4CH, DI (0–30V Input), Pulled up to 5V via 10KOhm |
|
Relay Output |
1CH, Dry contact Relay (30VDC/250VAC), NO/COM/NC (Terminal Block) |
| Storage |
Internal SD |
1 x Internal SD Card Slot |
|
NVMe SSD |
1 x M.2 M-Key Slot (for M.2 2280 NVMe SSD), Recording license 4-ch (OPTION) |
| ETC |
Watchdog |
Yes |
|
RTC |
Yes |
|
Cooling Fan |
– |
|
Factory Reset Button |
Yes |
|
LED Indicators |
1 x PWR LED (3 Color), 1 x Status LED (3 Color) |
| Power |
Power Supply |
12V/3.3A adaptor, DC +9V ~ +36V (DC Input Voltage) |
|
Power Consumption |
6.7 Watts (Without NVMe SSD) |
| Environment |
Temperature / Humidity |
-30°C ~ 70°C (-22°F~158°F) / 10~90% NC (Without NVMe SSD); -15°C ~ 50°C / 10~90% NC (With NVMe SSD) |
| Chassis |
Dimension (W x D x H) |
94 x 153 x 28 mm |
|
Weight (Net / Gross, KG) |
0.45 / 1.05 |
| Additional Information |
Mounting |
Desk, Wall |
|
Certification |
CE, FCC, KC, UKCA |
